Brick reinforcing mesh machine

Brick reinforcing mesh machine



The usage of the products:

It is laid between courses in blockwork and embedded in the mortar jointing. It forms an integral structure of great tensile strength which is resistant to stresses, vibrations and temperature changes. This machine can produce 2-4 line once time, according to the line width requirement.



The machine line including:

1.material De-coiler:  material can put: 1-2 TON

                  SIZE: 1000*800*800MM

                  WEIGHT: 600KGS

2.Mesh pounding machine:  motor：4.5KW

                    Mesh size: according requirement

                    Punching press: 25T

                    Material thickness: 0.2--0.7mm

                    Max width: 20cm( two strip for width is 20cm, 10cm can be 4 strip)

                    Punching speed: 150 stocks/min  about5-6m per min

3.Mesh re-coiler:  motor:1.5kw
